Using the outer and inner layers composed of slats, Mineal fibre compositus fire resistant shutter with arcuate shape design two kinds of plate-shaped sub peace to choose, which is handsome in appearance, strong rigidity and sealing characteristics. The main performance is better than a single layer of steel fire shutter.The technical indicators have been tested and qualified by the national authority.
| Model number | DIAN-F1602 |
| Material | |
| Curtain Material | Mineral fibre |
| Curtain color | Blue(Customized) |
| Opening and closing speed | 0.6-1.2 M/min |
| Open style | Automatic |
| Refractory limit time | > 3 hours |
| Curtain protection | Water spray system |
| Application | Commercial Building, Industrial Building, such as hotel, underground garage |
| Dimensions | |
| Door size | Customized |
| Curtain Thickness | 15mm |
| Guide Rail Thickness | 1.5mm |
| Operating noise | ≥50 dB |
| Packing & Delivery | |
| Packing | Plastic Protection Foam between each sections. Wooden case or carton packing |
| Delivery time | 15~30 days after receive the deposit |
| MOQ | 1 set |
